| CPU |
Intel Celeron Processor J1900 2GHz |
| Memory |
4GB Dual-channel DDR3L 1600 MHz |
| Storage |
128G DOM |
| OS |
Windows 7 Standard Embedded |
| KVS Software (Optional) |
Heng Yu Easy-KVS (ver 1.1) |
| Viewing Area |
17 inches |
| Resolution |
1280 x 1024 |
| Active Display Area (mm) |
337.920(W) x 270.336(H) |
| Display Color |
16.7Mcolors |
| Response Time |
8 ms |
| Contrast Ratio |
1000:1 (typ.) |
| Viewing Angle |
80°U / 80°D/ 85°L / 85°R |
| Luminance |
350 cd/m2 @ 7.5mA |
| Interfaces |
LAN : 10/100/1000Mbps
USB : 2 x USB type A Female
RS232 : Standard DB9 Male
Audio : 3.5mm Audio Jack |
| Power Adaptor |
Input : Universal AC100~240V, 50/60Hz
Output : DC +12V,5A |
| Power |
Management : VESA DPMS
Consumption : 24 ≦ W |
| Environment |
Storage Temperature : -25 ~ 70 ℃ ℃
Operating Temperature : 0 ~ 42 ℃ ℃
Operating Humidity : 10% ~ 85% |
| Mounting |
VESA (100mm x 100mm) |
| Dimensions |
Product : 433.5 x 367 x 55.5mm
Packaging : 450 x 560 x 60mm |
| Touch panel |
ELO 5-wire resistive |
| Metal Keypad |
MK15E (Stainless keys, IP65) |
