Built to last
With the durability of the renowned industrial PowerScan family, the PowerScan imager is now being introduced into the retail sector with anew series of ‘Retail’ scanners. The PowerScan PD9500-RT imager is a corded scanner perfect for desk applications. The rugged mechanics of the PowerScan Retail series guarantee reliable long-term operation in retail activities. Repeated shocks at the POS checkout does not inhibit the scanner performance or reliability, protecting the retailer’s investment. The IP65 rating further guarantees protection from damages caused by exposure to moisture.
Now with digital watermarking
Digital watermarked bar codes include the same Global Trade Item Number (GTIN) data contained in the UPC/EAN symbologies, but repetitively distributes the GTIN data across the entire packag without altering the packaging aesthetics. The PowerScan Retail 9500 series is the first handheld series of scanners on the market capable of reading digital watermarks including Digimarc Barcodes. This new application significantly reduces time at the checkout. Cashiers can scan items quicker without having to hunt for the bar code or lift bulky items from the trolley.
Mobility enhances productivity
The PowerScan PD9500-RT Retail series can be used for all desktop activities at the POS checkout. To coordinate with different POS systems, the imagers are offered in 2 colors: dark gray or white with a silver top cover.
Features
- Outstanding robustness (2.0 m / 6.6 ft drops) and an IP65 sealing rating
- Vertical cradle for presentation mode scanning
- Digital watermarks including Digimarc Barcodes
- Snappy omnidirectional reading
- Intuitive aiming system
- In-field replaceable window
- Datalogic’s 3GL (3 Green Lights) technology and loud beeper for good-read feedback
- Datalogic’s Motionix™ motion-sensing technology
- Ergonomic shape
- EASEOFCARE Service Plans offer a wide range of service options to protect your investment, ensuring maximum productivity and ROI
Industry Applications
- Retail : Point of Sale Checkout,Shelf Replenishment,Goods Receiving,Inventory
- Healthcare : Patient Tracking
- Commercial Services : Postal,Banks,Public Administration,Utilities
| Digital Watermarks |
Includes Digimarc Barcodes |
| 1D / Linear Codes |
Autodiscriminates all standard 1D codes including GS1 DataBar linear codes. |
| 2D Codes |
Aztec Code; China Han Xin Code; Data Matrix; MaxiCode; Micro QR Code; QR Code |
| Stacked Codes |
EAN/JAN Composites; GS1 DataBar Composites; GS1 DataBar Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional; MacroPDF; MicroPDF417; PDF417; UPC A/E Composites |
| Postal Codes |
Australian Post; China Post; IMB; Japanese Post; KIX Post; Planet Code; Portuguese Post; PostnetRoyal Mail Code (RM4SCC); Swedish Post |
| Current |
Operating (Typical): 335 mA @ 10 VDC
Standby/Idle (Typical): 180 mA @ 10 VDC |
| Input Voltage |
5 VDC +/- 10% |
| Ambient Light |
0 – 100,000 lux |
| Drop Resistance |
Withstands repeated drops from 2 m / 6.6 ft onto a concrete surface. |
| ESD Protection (Air Discharge) |
20 kV |
| Humidity (Non-condensing) |
95% |
| Particulate And Water Sealing |
IP65 |
| Temperature |
Operating: -20 to 50 °C / -4 to 122 °F
Storage/Transport: -40 to 70 °C / -40 to 158 °F |
| Interfaces |
RS-232; USB COM; USB HID Keyboard |
| Colors Available |
Dark Gray / Black; White / Light Gray |
| Dimensions |
21.2 x 11.0 x 7.4 cm / 8.3 x 4.3 x 2.9 in |
| Weight |
330.0 g / 11.6 oz |
| Imager Sensor |
864 x 544 |
| Light Source |
Aiming: 630 – 680 nm VLD
Illumination: Red LEDs |
| Motion Tolerance |
90 cm / 35 in per second |
| Print Contrast Ratio (Minimum) |
15% |
| Read Angle |
Pitch: +/- 40°; Roll (Tilt): 360°; Skew (Yaw): +/- 40° |
| Reading Indicators |
Beeper (Adjustable Tone and Volume); Datalogic’s 3GL (Three Green Lights) technology and loud beeper for good-read feedback; Datalogic ‘Green Spot’ on the Code; Dual Good Read LEDs |
| Resolution (Maximum) |
1D Codes: 4 mils; 2D Codes: 7.5 mils |
| Depth Of Field |
Minimum distance determined by symbol length and scan angle.Printing resolution, contrast, and ambient light dependent. |
| Digital Watermarking |
Maximum: 30 cm / 11.8 in |
| 1D / 2D Codes |
4 mils: 6.0 to 17.0 cm / 2.3 to 6.7 in
13 mils: 4.0 to 45.0 cm / 1.5 to 17.7 in
20 mils: 4.0 to 55.0 cm / 1.5 to 21.6 in
40 mils: 4.0 to 85.0 cm / 1.5 to 33.4 in
10 mils PDF417: 2.0 to 25.0 cm / 0.8 to 9.8 in
7.5 mils Data Matrix: 9.0 to 12.0 cm / 3.5 to 4.7 in
10 mils Data Matrix: 4.0 to 18.0 cm / 1.5 to 7.0 in |
| Agency Approvals |
The product meets necessary safety and regulatory approvals for its intended use.The Quick Reference Guide for this product can be referred to for a complete list of certifications. |
| Environmental Compliance |
Complies to EU RoHS,Complies to EU RoHS,Complies to R.E.A.C.H. |
| Laser Classification |
Caution Laser Radiation – Do not stare into beam CDRH Class II; IEC 60825 Class 2 |
| LED Classification |
IEC 62471 Exempt Class |
| Datalogic Aladdin |
Datalogic Aladdin configuration program is available for download at no charge. |
| OPOS / JavaPOS |
JavaPOS Utilities are available for download at no charge.
OPOS Utilities are available for download at no charge. |
| Remote Host Download |
Available on request |
| Warranty |
3-Year Factory Warranty |
