| Resolution |
8 dots/mm (203 DPI) |
| Printing method |
Thermal Transfer & Direct Thermal |
| Max. print speed |
127 mm (5”)/second |
| Max. print width |
54 mm (2.13“) |
| Max. print length |
2,286 mm (90“ |
| Enclosure |
Clamshell design with double walled plastic |
| Physical dimension |
140 mm (W) x 177 mm (H) x 241 mm (D)
5.51“ (W) x 6.97“ (H) x 9.49“ (D) |
| Weight (including battery) |
2.45 kg (5.4 lbs |
| Label roll capacity |
127 mm (5“) OD |
| Ribbon |
90 m long, max. OD 37 mm, 0.5“ core (ink coated outside) |
| Ribbon width |
56 ~ 58 mm (2.20” ~ 2.28” |
| Processor |
32-bit RISC CPU |
| Memory |
4 MB Flash memory, 8 MB SDRAM
microSD card reader for Flash memory expansion, up to 4 GB |
| Interface |
USB 2.0
RS-232
USB host, for scanner or PC keyboard (factory option)
Internal Ethernet, 10/100 Mbps (factory option)
Bluetooth (user option)
External 802.11 b/g/n wireless (user option) |
| Power |
External universal switching power supply
Input: AC 100-240V, 50-60Hz, 1.8A
Output: DC 24V, 2.5A, 60W |
| Operation switch, button |
1 power switch, 1 feed button & 3 LED (Power, Error, On-line) |
| Sensors |
Transmissive gap sensor
Black mark reflective sensor
Ribbon end sensor
Head open sensor |
| Internal fonts |
8 alpha-numeric bitmap fonts
Monotype Image true type font engine with one CG Triumvirate Bold Condensed scalable font |
| Real time clock |
Standard |
| Bar code |
1D bar code: Code 39, Code 93, Code 128UCC, Code 128 subset A, B, C, Codabar, Interleave 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2 (5) digits add-on, MSI, PLESSEY, POSTNET, RSS-Stacked, GS1 DataBar, Code 11
2D bar code : PDF-417, Maxicode, DataMatrix, QR code, Aztec |
| Font and barcode rotation |
0, 90, 180, 270 degree |
| Printer language |
TSPL-EZ(Compatible to EPL, ZPL, ZPL II) |
| Media type |
Continuous, black mark, fan-fold, notched, wristband (outside wound) |
| Media width |
15 ~ 60 mm (0.59” ~ 2.36” |
| Media thickness |
0.06 ~ 0.19 mm (2.36 ~ 7.48 mil) |
| Media core diameter |
25.4 ~ 38 mm (1” ~ 1.5”) |
| Label length |
6 ~ 2,286 mm (0.24” ~ 90”) |
| Environment condition |
Operation: 5 ~ 40°C, 25 ~ 85% non-condensing
Storage: -40 ~ 60°C, 10 ~ 90% non-condensing |
| Safety regulation |
FCC Class B, CE Class B, C-Tick Class B, UL, CUL, TÜV/Safety, CCC |
| Environmental concern |
Comply with RoHS, WEEE |
| Accessories |
Windows labeling software CD disk
Quick start guide
Power cord
External universal switching power supply
USB Cable |
| Limited warranty |
Printer: 2 years
Print head: 25km (1 million inches) or 12 months which comes first
Platen: 50km (2 million inches) or 12 months which comes first |
| Factory options |
128 x 64 pixels graphic type LCD display with back light
USB host, for scanner or PC keyboard |
| User options |
Bluetooth module (serial interface)
802.11 b/g/n wireless module (serial interface)
KP-200 Plus keyboard display unit
KU-007 Plus programmable smart keyboard |
| Dealer options |
Internal Ethernet interface (10/100 Mbps)
Peel-off module
Guillotine cutter (full cut and partial cut) |
